The Poline brass ball valve Male x Female (M x F) with lever handle is a high-performance valve designed for precise flow control in gas, oil, air, and water applications. Manufactured using IS 6912 forged nickel-plated brass, it ensures superior strength, corrosion resistance, and long service life.

With a full bore design and quarter-turn operation, this valve provides smooth flow and reliable shut-off in threaded piping systems.

Key Features

• Full bore design for maximum flow efficiency
• Two-piece construction with quarter-turn operation
• Lever handle for easy and quick operation
• Made from IS 6912 FLB high-strength forged brass
• Nickel-plated finish for corrosion resistance
• PTFE seats for leak-proof sealing
• Male x Female threaded ends (M x F)

Designed for reliable flow control in threaded piping systems

Applications​

• Air and pneumatic systems
• Water supply and plumbing systems
• Industrial utilities

Mini and MxF valves are widely used in compact and threaded piping applications across industries

Technical Specifications

• Working Pressure : Up to 16Bar
• Temperature : -20°C to +120°

Why Choose Poline M x F Ball Valve

• Strong forged construction for durability
• Easy installation with M x F threaded connection
• Suitable for multiple media (air, water)
• Long service life with minimal maintenance

FAQ

Q1. What is M x F ball valve?
It means Male x Female threaded connection used for easy installation between pipeline fittings.

Q2. Where is M x F ball valve used?
It is used in water and air pipelines with threaded connections.

Q3. What is the pressure rating?
The valve is suitable for working pressure up to 16 bar.
