Single Plate Check Valve With SG iron Disk PN 1.6
| SUITBLE FOR | ||||
|---|---|---|---|---|
| GASES | AIR | STEAM | OIL | WATER |
Salient Features
- Pressure/Class /Rating : PN-16
- Type of Seat : EPDM
- Type of Disc : SG iron disk
- End Details : Wafer Type
Technical Data
- Body Test Pressure : 24kg/cm²g (Hyd.)
- Seat Test Pressure : 16kg/cm²g (Hyd.)
| MATERIAL LIST | ||||
|---|---|---|---|---|
| P.NO | Name Of Part | Material of Constuction | Specifications | Qty. |
| SIZE / DIMENSIONS | |||||
|---|---|---|---|---|---|
| Size(mm) | A+1.5 | B | OC | OD+5.0 | E(MAX.) |
The information provided here serves as guidelines only and is subject to possible modification.
