Cast Iron Ball Type Foot Valve (S/E)
Cast Iron Ball Type Foot Valve (S/E)
Product Overview
The Poline Cast Iron Ball Type Foot Valve – Screwed End is designed for pump suction applications where maintaining prime and preventing reverse flow are critical. Installed at the bottom of suction lines, this valve allows water to flow upward while automatically stopping backflow when the pump stops.
Built with a strong cast iron body, this ball type foot valve offers rugged durability for agricultural, domestic, industrial, and water transfer systems. The free-moving ball mechanism provides dependable sealing with low maintenance and smooth operation.
Its screwed end connection ensures easy installation in threaded pipe systems.
Key Features
- Heavy duty cast iron body construction
- Ball type self-closing mechanism
- Prevents reverse flow and maintains pump prime
- Suitable for suction line installation
- Screwed end threaded connection
- Low maintenance moving parts
- Rugged design for long service life
- Reliable sealing performance
- Easy installation and replacement
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Ball Type Foot Valve |
| Body Material | Cast Iron |
| End Connection | Screwed End |
| Valve Type | Ball Type Non Return |
| Size Range | 1/4" to 4" |
| Media | Water / Utility Liquids |
| Installation | Pump Suction Line |
| Operation | Automatic |
Applications
The Poline Cast Iron Ball Type Foot Valve is widely used in:
- Domestic water pumps
- Agricultural irrigation pumps
- Borewell / openwell suction lines
- Industrial water transfer systems
- Construction water pumping
- Tank suction systems
- Utility water handling systems
Why Choose Poline Foot Valves?
Poline Valves manufactures dependable pumping accessories designed for long service life and efficient water handling. Our foot valves help maintain prime, protect pumps, and improve system reliability.
Frequently Asked Questions
1. What is a foot valve used for?
A foot valve is installed on the pump suction line to stop backflow and keep the pump primed.
2. What is a ball type foot valve?
It uses a floating ball mechanism that opens during suction flow and closes automatically when flow stops.
3. Where is this valve installed?
It is installed at the lower end of the suction pipe, usually inside a sump, tank, or water source.
4. Is cast iron suitable for foot valves?
Yes, cast iron provides strength and durability for water pumping systems.
5. What sizes are available?
This model is available from 1/4 inch to 2 inch.
Request a Quote
For pricing, dealership enquiries, OEM supply, or bulk orders for Cast Iron Ball Type Foot Valve (S/E), contact Poline Valves today.
| MATERIAL LIST | ||||
|---|---|---|---|---|
| Part No | Part Name | Material | Specification | Qty |
| 1 | BODY | Cast Iron | - | 1 |
| SUITABLE FOR | ||||
|---|---|---|---|---|
| GASES | AIR | STEAM | OIL | WATER |
| SIZE DESCRIPTION |
|---|
a
The information provided here serves as guidelines only and is subject to possible modification.Related Products
